Current Signal Output Pressure Transmitter
posttime£º1899-12-30  Font ¡¼ B M S ¡½  Readtime£º   [Close]

Current Signal Output Pressure Transmitter

  • high sensitivity ,
  • low temperature drift£¬high linearity, high overload pressure£¬
  • excellent stability£¬rapid response and excellent EMC.
Measurement range  £º  0~5 MPa                          Overload pressure £º 300% FS
Operating temperature £º-45~125¡æ                      Voltage £º  5VDC¡¢12VDC¡¢24VDC
Overload voltage £º16VDC¡¢36VDC¡¢40VDC            Output current£º 4~20 mA
Vibration £º   10g£¨20~5000Hz£©                           Drop£º 1m
Impact£º  20g                                                      Response£º 0.3V/¦Ìs
EMC£º  100 V/m  30MHz~1GHz                              ESD£º 15kV
Zero temperature coefficient £º  ¡À0.001~ ¡À0.015 %FS/¡æ(-25¡æ ~125¡æ)
Full-Span temperature coefficient £º-0.001~ -0.015 %FS/¡æ(-25¡æ ~ 125¡æ)
Accuracy £º0.1%,0.2%,0.5%,1%,2%,3%(including linearity£¬hysteresis£¬repeatability)
Our products are conform to the auto standards of ISO7637
